Sage Relay — SR-Series Module
SR7
SR7Sage Relay for high-bay luminaires (up to 4 drivers) with normal power from 50 W to 400 W+. Converts any LED luminaire operating on normal AC or 24 VDC power to low-voltage emergency operation from a Sage central-battery system — constant power, factory-adjustable to optimize the emergency level. Fixtures may be on, off, switched, or dimmed in normal mode without affecting emergency operation. Output voltage auto-senses up to 210 V.
CB COMPATIBLE
Powers from central battery
HIGH-BAY
50–400 W luminaires
4-CHANNEL
Up to 4 drivers
ADJUSTABLE
15–60 W factory-set
Documents
Submittal documents for SR7 — preview inline or download.
Construction & Operation
- Extruded-aluminum housing with mounting rails.
- Factory or field installable in the fixture Fire & Electrical Enclosure.
- Up to 4-channel output — operates luminaires with up to 4 drivers. Input option to 480 VAC.
- Sage Live-ready — fault-monitored system component.
- Normal lighting unaffected; all dimming & controls; ≥ 90-min.
Ordering Information
Module variant selected by Sage per project.
Sage-Specified Module
Sage's engineering team selects the appropriate SR7 variant for each project based on fixture load, voltage, and system architecture. Specifiers and agents do not self-specify SR7 modules.
Emergency output range (reference)
15W20W25W30W40W50W60W
Available configurations (reference)
V1V1 — Output voltage range 60-210VDC (100-290 mA)
CHXCHX — X Channels (X = number of normal drivers installed, up to 4)
HVHV — 347/480 VAC Input
host-rangeHost fixture normal-mode range: 50-400W+ LED (high-bay)
output-maxEmergency output: adjustable 15-60W, up to 210V auto-sense, up to 4 channel output
To spec a project that includes SR7, contact Sage — we'll select the right module and deliver the final SKU with your submittal package.
Contact Sage
