Sage Relay — SR-Series Module
SR1
SR1Sage Relay for downlights and other compact, limited-space luminaires with normal power from 10 W to 70 W+. Converts most LED luminaires operating on normal AC or 24 VDC power to low-voltage emergency operation from a Sage central-battery system — constant power, factory-adjustable to optimize the emergency level. Fixtures may be on, off, switched, or dimmed in normal mode without affecting emergency operation. Output voltage auto-senses up to 41 V.
CB COMPATIBLE
Powers from central battery
COMPACT
Limited-space fit
AUTO-SENSE
Output to 41 V
ADJUSTABLE
5–22 W factory-set
Documents
Submittal documents for SR1 — preview inline or download.
Construction & Operation
- Compact module — smallest footprint.
- Factory or field installable in the fixture Fire & Electrical Enclosure.
- High-efficiency 90% @ 24 VDC; OVP / SCP / OTP protection.
- Sage Live-ready — fault-monitored system component.
- Normal lighting unaffected; all dimming & controls; ≥ 90-min.
Ordering Information
Module variant selected by Sage per project.
Sage-Specified Module
Sage's engineering team selects the appropriate SR1 variant for each project based on fixture load, voltage, and system architecture. Specifiers and agents do not self-specify SR1 modules.
Emergency output range (reference)
5W10W15W20W22W
Available configurations (reference)
V3V3 — Output voltage range 5-22V (V3 only)
host-rangeHost fixture normal-mode range: 10-70W LED
output-maxEmergency output: adjustable 5-22W, up to 41V auto-sense
To spec a project that includes SR1, contact Sage — we'll select the right module and deliver the final SKU with your submittal package.
