- Us Patent
- U.S. Patent 5,276,591
- Mounting
- Field selectable wall or ceiling mount. No exposed hardware.
- Continuous
- Continuous Monitoring with 1-Second Sampling — Lamp Connections, Battery Connections.
- Every 28 Days
- Transfer switch function; Battery discharge rate under full load; Test switch indicator function.
- Every 12 Months
- Full 90 minute emergency operation test with test/fail and manual report signal.
- Wall Mount
- Sign face 13" W x 7 1/2" H; canopy 5" wide; 1 7/8" lamp-housing tube profile; 1 1/2" wall-face-to-housing standoff.
- Top Mount
- Ceiling-to-sign-bottom drop 10" (single face); double-face shown with charge/test/status indicators boss.
- Pendant Mount
- 5" canopy; 12" STD or custom length drop; 3/4" dia stem.
- End Mount
- 1 1/2" extension; recessed light bar & power supply (free lens).
- Mullion Mount
- Fits a 2" mullion (OPA mullion).
- Inverted Surface Mount
- OPA mullion — inverted exit legend & canopy mount for difficult mounting situations.
- J Box
- BB & NB models: standard deep 4" x 4" x 2 1/8" J-box with 1 1/2" extension ring. Remote models (CBS & master-remote): standard 4-O J-box 3 1/2" x 3 1/2" x 1 1/2".
- Note Jbox
- PRE-INSTALL 4" x 4" x 2 1/8" DEEP J-BOX WITH 1 1/2" EXTENSION RING FOR BB & NB MODELS.
- Warranty
- 5 year total customer satisfaction warranty. For details see product catalog technical data section.
- Operating Temp
- Standard Operating Temperature: 0°C to 50°C.
- Lamp Housing Canopy
- extruded aluminum
- Graphic Lenses
- optical grade acrylic with diamond polished edges
- Lighting Uniformity
- better than 4:1
- Average Brightness
- 6 ft-Lambert (21 cd/m²)
- Led Life Expectancy
- in excess of 20 years
- Ac Supply
- universal 120/277 VAC input via two-wire feed
- Emergency Operation
- 90 minutes for each sign
- Battery Recharge
- less than 24 hours
