Extended Catalog
A Sage-selected OEM product, specified and supported by Sage. Buy American projects specify from the Signature Series.
Specifications
- Ac Operation
- Dual 120/277 voltage.
- Indicators Testing
- Charge rate/power 'ON' LED indicator light and push-to-test switch for mandated code compliance testing.
- Battery
- 4.8V long life, maintenance-free, rechargeable NiCd battery (BB models only).
- Transfer Switch
- Internal solid-state transfer switch automatically connects the internal battery to the LED board for minimum 90-minute emergency illumination.
- Charger
- Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours.
- Emergency Runtime
- Minimum 90-minute emergency illumination.
- Recharge
- Recharges a discharged battery in 24 hours (two-rate solid-state charger).
- Overall Width
- 14 3/4 in
- Lens Width
- 13 1/8 in
- Height
- 9 in
- Depth
- 2 5/8 in
- Catalog Number
- NIM-RED/GREEN/BB/SDT
- Operating Temp
- -20°C to 50°C (UL Listed for wet locations)
- Warranty
- Five year warranty on all electronics and housing. Battery prorated for five years.
