Specifications
- Illumination
- Ultra-bright, energy efficient, long-lasting white LEDs provide uniform illumination.
- Self Contained Battery
- 4.8V long life, maintenance-free, rechargeable NiCd battery (EM models only). Internal solid-state transfer switch automatically connects the internal battery to the LED board for minimum 90-minute emergency illumination; fully automatic solid-state two-rate charger recharges a discharged battery in 24 hours.
- Ac Dc Note
- Order operation per the ordering table: BB = 120/277VAC with Battery (self-contained EM) · NB = AC only · REC = Sage central battery (DC). DC inputs available as REC-model options: 48 = 48VDC input, 60 = 60VDC input.
- Housing Width In
- 14 3/8 (outer) / 13 7/8 (inner)
- Canopy Width In
- 6
- Housing Height In
- 9 - 10
- Canopy Depth In
- 6
- Mount
- Back mount (universal knockout pattern + gasket) or top/end mount via included polycarbonate canopy.
